Structural H Beam Steel – High-strength section steel for construction and steel structures.
Multiple Standards Available – ASTM, EN, JIS, GB, BS and customized standards supported.
Custom Sizes & Lengths – Standard H beams, wide flange beams and welded H beams available.
Surface Treatment Options – Black steel, painted, galvanized or anti-corrosion coating.
Export Ready Supply – MTC, inspection support, cutting service, FOB, CIF and CFR available.
H beam steel is a structural steel profile with an H-shaped cross section. It has wide flanges, a straight web, high section modulus, and strong load-bearing performance. Compared with many traditional steel profiles, H beam steel provides better bending resistance, higher structural stability, and more efficient material utilization.
Because of its excellent mechanical performance and convenient installation, H beam steel is widely used in steel structure buildings, bridges, factories, warehouses, platforms, machinery frames, shipbuilding, infrastructure, and large-span construction projects.
Henan GDD supplies hot rolled H beams, welded H beams, wide flange beams, and customized structural steel sections. We support different steel grades, standards, lengths, surface treatments, cutting services, inspection requirements, and export shipment solutions.
| Item | Specification |
|---|---|
| Product Name | H Beam Steel / H Section Steel / Wide Flange Beam |
| Type | Hot Rolled H Beam, Welded H Beam, Wide Flange Beam, Customized Steel Beam |
| Material Grade | Q235B, Q345B, Q355B, SS400, S235JR, S275JR, S355JR, ASTM A36, ASTM A572 Gr.50 or Customized |
| Standard | GB, ASTM, EN, JIS, BS or Customized |
| Web Height | 100 mm – 900 mm or Customized |
| Flange Width | 50 mm – 400 mm or Customized |
| Web Thickness | 5 mm – 30 mm or Customized |
| Flange Thickness | 7 mm – 40 mm or Customized |
| Length | 6m, 9m, 12m or Customized |
| Surface Treatment | Black Steel, Painted, Galvanized, Anti-corrosion Coating |
| Processing Service | Cutting, Drilling, Welding, Punching, Surface Treatment |
| Inspection | MTC, Dimension Inspection, Surface Inspection, Third-party Inspection |
| Application | Construction, Steel Structure, Bridge, Warehouse, Factory, Platform, Machinery |
| Packing | Bundle Packing or Customized Export Packing |
| Trade Terms | FOB, CFR, CIF, EXW |
H beam steel is a structural steel section named after its H-shaped cross section. It consists of two wide flanges and one vertical web. The flanges mainly resist bending force, while the web helps resist shear force and maintain structural stability.
H beams are widely used in modern steel structure engineering because they provide high strength, good rigidity, convenient connection, and efficient load transfer. They can be used as columns, beams, supports, frames, bridge components, and industrial structural members.
Depending on production process, H beams can be divided into hot rolled H beams and welded H beams. Hot rolled H beams are commonly used for standard construction applications, while welded H beams are often used for large sizes, customized dimensions, and heavy structural projects.
Hot rolled H beam is produced through hot rolling process with stable dimensions, good mechanical performance, and high production efficiency. It is commonly used in steel structure buildings, warehouses, bridges, platforms, and general construction projects.
Welded H beam is fabricated by welding steel plates into H-shaped sections. It is suitable for large-size, heavy-duty, and customized structural applications where standard hot rolled sizes cannot fully meet project requirements.
Wide flange beam has wider flanges and strong bending resistance. It is widely used as structural columns, beams, frames, and load-bearing members in construction and industrial projects.
Customized H beams can be supplied according to drawings, project design, steel grade, length, hole position, surface treatment, and processing requirements.
| Grade | Standard | Feature | Common Application |
| Q235B | GB | Economical structural steel with good weldability | General construction and steel structures |
| Q355B | GB | Higher strength and good mechanical performance | Bridges, heavy structures, industrial buildings |
| SS400 | JIS | General structural steel | Construction, machinery, fabrication |
| S235JR | EN | General structural grade | Buildings, platforms, steel frames |
| S275JR | EN | Medium strength structural steel | Construction and machinery structures |
| S355JR | EN | High-strength structural steel | Bridges, heavy-duty structures, warehouses |
| ASTM A36 | ASTM | Common carbon structural steel | Buildings, frames, supports |
| ASTM A572 Gr.50 | ASTM | High-strength low-alloy steel | Bridges, heavy construction, structural projects |
H beam steel is one of the most widely used structural steel materials in construction and industrial engineering.
| Application Area | Typical Use |
| Steel Structure Buildings | Columns, beams, frames, roof supports |
| Warehouses and Factories | Main structure, roof frame, support frame |
| Bridge Construction | Bridge beams, support structures, reinforcement members |
| Industrial Platforms | Equipment platforms, working platforms, stair supports |
| Machinery Manufacturing | Machine base, frame, heavy equipment support |
| Shipbuilding | Structural parts, hull support, marine frames |
| Infrastructure Projects | Stations, terminals, public buildings, large-span structures |
| Prefabricated Buildings | Modular houses, steel frame buildings, container structures |
H beam steel has an optimized cross-section design with wide flanges and strong web support, allowing it to bear heavy vertical and horizontal loads.
The H-shaped profile provides strong bending resistance and good structural rigidity, making it suitable for large-span buildings and heavy-duty engineering projects.
Compared with some traditional steel sections, H beam steel can provide high strength while helping reduce structural weight and material consumption.
H beams can be welded, bolted, cut, drilled, and connected easily, improving construction efficiency and reducing on-site installation time.
Different sizes, standards, steel grades, lengths, and surface treatments can be supplied according to customer project requirements.
H beam steel can be used for permanent steel structures as well as temporary support frames, construction platforms, and project facilities.
| Item | Hot Rolled H Beam | Welded H Beam |
| Production Method | Hot rolling process | Welding steel plates into H section |
| Size Range | Standard sizes | More flexible custom sizes |
| Surface Appearance | Rolled surface | Welded seam visible |
| Common Use | General buildings, warehouses, platforms | Heavy-duty structures and special projects |
| Cost | Usually more economical for standard sizes | Better for customized large sections |
| Delivery | Faster when standard sizes are available | Depends on fabrication requirements |
Henan GDD is a reliable steel material supplier with experience in structural steel supply, processing, inspection, packing, and export service. We provide H beam steel solutions for construction companies, steel structure factories, bridge contractors, machinery manufacturers, infrastructure projects, and global steel distributors.
| Advantage | Description |
| Multiple Product Types | Hot rolled H beam, welded H beam, wide flange beam and customized sections available |
| Various Standards | GB, ASTM, EN, JIS, BS and customized standards supported |
| Custom Processing | Cutting, drilling, welding, punching and surface treatment available |
| Stable Quality | Accurate dimensions, strong structure and reliable mechanical performance |
| Quality Inspection | MTC, dimension inspection, surface inspection and third-party inspection available |
| Export Support | Packing, loading, documents and international shipment support |
| One-stop Service | Quotation, production, inspection, packing and shipping arrangement |
Before shipment, Henan GDD can arrange inspection according to customer requirements and project specifications.
| Inspection Item | Details |
| Dimension Inspection | Web height, flange width, web thickness, flange thickness and length check |
| Surface Inspection | Rust, cracks, deformation, scratches and visible defects check |
| Straightness Check | Beam straightness and end condition inspection |
| Weight Inspection | Unit weight and total quantity confirmation |
| Processing Check | Cutting length, drilling size, hole position and welding quality if required |
| Material Certificate | MTC and quality documents available |
| Third-party Inspection | SGS, BV, Intertek or customer-appointed inspection accepted |
H beam steel is usually packed in bundles with steel strips. For large sizes or heavy structural beams, packing and loading can be arranged according to project quantity, length, destination port, and shipment method.
| Item | Details |
| Packing Method | Steel strip bundle, export standard packing |
| Marking | Grade, size, heat number, bundle number if required |
| Length Options | 6m, 9m, 12m or customized |
| Loading Method | Container, bulk vessel, break bulk or customized shipment |
| Documents | Commercial Invoice, Packing List, Bill of Lading, MTC, COO if required |
| Trade Terms | FOB, CFR, CIF, EXW |
H beam steel is mainly used for steel structure buildings, warehouses, factories, bridges, platforms, machinery frames, shipbuilding, infrastructure projects, and prefabricated buildings.
H beam usually has wider flanges and better load distribution, making it suitable for heavy-duty structural applications. I beam has narrower flanges and is often used in lighter structural applications depending on design requirements.
Yes. We can supply hot rolled H beams, welded H beams, wide flange beams, and customized H sections according to project requirements.
Common grades include Q235B, Q355B, SS400, S235JR, S275JR, S355JR, ASTM A36, and ASTM A572 Gr.50. Other grades can be confirmed according to your specification.
Yes. Cutting, drilling, welding, punching, and surface treatment can be arranged according to customer drawings or project requirements.
Please provide standard, steel grade, size, length, quantity, surface treatment, processing requirement, destination port, and trade terms.
Yes. MTC, quality documents, inspection photos, packing photos, loading photos, and third-party inspection can be provided according to order requirements.
Looking for H beam steel for construction, bridges, warehouses, or steel structure projects?
Send us your required standard, grade, size, length, quantity, and destination port. Henan GDD will provide a professional quotation and suitable shipping solution.
